1.Material:Monel wire:monel 400 and monel 500
2.Mesh Count:2-200mesh
3.Weave Pattern:Plain weave, twill weave, dutch weave.
4.Features:Monel is highly resistant to the corrosive action of acids,
alkalies and salt water. It has the same strength of mild steel.
5.Applications: Monel Woven Wire Mesh is often used in marine applications such as
piping systems and strainer baskets as well as in chemical
processing equipment and heat exchangers
6.Packing:Waterproof paper with plastic cloth,then put into wooden box.
7.The Most Popular Specification:
Monel Wire Mesh | ||
Mesh | Wire Diameter(mm) | Aperture(mm) |
2 | 1.80 | 10.90 |
3 | 1.60 | 6.866 |
4 | 1.20 | 5.15 |
5 | 0.91 | 4.17 |
6 | 0.80 | 3.433 |
8 | 0.60 | 2.575 |
10 | 0.55 | 1.990 |
12 | 0.50 | 1.616 |
14 | 0.45 | 1.362 |
16 | 0.40 | 1.188 |
18 | 0.35 | 1.060 |
20 | 0.30 | 0.970 |
26 | 0.28 | 0.696 |
30 | 0.25 | 0.596 |
40 | 0.21 | 0.425 |
50 | 0.19 | 0.318 |
60 | 0.15 | 0.273 |
70 | 0.14 | 0.223 |
80 | 0.12 | 0.198 |
90 | 0.11 | 0.172 |
100 | 0.10 | 0.154 |
120 | 0.08 | 0.132 |
140 | 0.07 | 0.111 |
150 | 0.065 | 0.104 |
160 | 0.065 | 0.094 |
180 | 0.053 | 0.088 |
200 | 0.053 | 0.074 |
|
|
